Electric Rotary Table LERProduct Category:Rotary Tables

Product Introduction:
·Swing angles: 360 °, 320 ° (310 °), 180 °, 90 °() is the value of LER10·Thin: Height dimension 42mm (LER10)·Built in stepper motor, achieving space saving·No impact, high-speed driveMaximum speed: 420 °/sec (7.33 rad/sec)Maximum accelerati
Call the ordering phone number Back

Product Introduction

    ·Swing angles: 360 °, 320 ° (310 °), 180 °, 90 °
    () is the value of LER10
    ·Thin: Height dimension 42mm (LER10)
    ·Built in stepper motor, achieving space saving
    ·No impact, high-speed drive
    Maximum speed: 420 °/sec (7.33 rad/sec)
    Maximum acceleration and deceleration: 3000 °/sec2 (52.36 rad/sec2)
    ·Speed, acceleration/deceleration, positioning up to 64 points
    ·Energy saving: After the table is stopped, the power automatically decreases by 40%
    ·Easy to set: simply set the position and speed as two options
    The controller is set according to the actuator specifications and shipped from the factory (actuator and controller are sold together)
    ·Corresponding controller/driver: JXC □ LEC □

    Note: Values with external limiters.
