Electric Actuator/Slider Type, Ball Screw Drive LEFSProduct Category:slider Type

Product Introduction:
LEFS series stepper motor (with encoder DC24V) servo motor (DC24V)·Maximum transportable weight: 65kg.·Repetitive positioning accuracy: ± 0.015mm (high-precision type).·Cleanliness specifications: can correspond to ISO level 4 (ISO14644-1) (11-LE
Call the ordering phone number Back

Product Introduction

    LEFS series stepper motor (with encoder DC24V) servo motor (DC24V)
    ·Maximum transportable weight: 65kg.
    ·Repetitive positioning accuracy: ± 0.015mm (high-precision type).
    ·Cleanliness specifications: can correspond to ISO level 4 (ISO14644-1) (11-LEFS).

    LEFS series AC servo motor
    ·High output motor (100W/200W/400W).
    ·Improved high-speed handling capability
    ·Corresponding to fast acceleration and deceleration (20000mm/S2).
    ·Pulse input type.
    ·Equipped with an absolute incremental encoder.
    ·Repetitive positioning accuracy: ± 0.01mm (high-precision type).
    ·Cleanliness specifications: can correspond to ISO level 4 (ISO14644-1) (11-LEFS).
    ·Whether there are motor specifications available. View details

    ·Corresponding controller/driver: JXC □ LEC □
