Battery-less Absolute EncoderTypeSEBA

menuproductsPRODUCT DISPLAY

Your location:Home >>Products >>SMC brand >>Electric Actuators/Cylinders >>Battery-less Absolute EncoderType

Battery-less Absolute Encoder Type Electric Actuator/Guide Rod Type LEYGProduct Category:Battery-less Absolute EncoderType

Product Introduction:
·Can restart the action from the stop position·After restoring power, the position can be stopped and restarted·Even if the power is cut off, the encoder can still save location information,Therefore, there is no need to perform an origin reset af
Call the ordering phone number Back

Product Introduction

    ·Can restart the action from the stop position
    ·After restoring power, the position can be stopped and restarted
    ·Even if the power is cut off, the encoder can still save location information,
    Therefore, there is no need to perform an origin reset after the power is restored
    ·Battery free, easier to maintain
    Due to the absence of batteries for storing location information,
    Therefore, there is no need to manage, maintain, or replace backup batteries
    ·The guide rod is compactly integrated, achieving resistance to lateral loads and high-precision anti rotation
    Lateral load at the pole end: 5 times (compared to products with a pole type, size 25, and 100 strokes)
    ·Corresponding to sliding bearings and ball sleeve bearings
    Suitable for lateral load resistance, blocking (sliding bearings), etc
    Switching for pressure touch control
    ·Can maintain the pressure contact state of the rod on the workpiece, etc
    Repetitive positioning accuracy: below ± 0.02mm

    ·Corresponding controller/driver: JXC □ LEC □
